Approx. Rs 22,912 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Weight | 460 g |
Square Drive | 1/4" |
Code | IST-WP12 |
Range | 2.4~12N.m |
Accuracy clockwise | +-3% |
Accuracy counter clockwise | +-4% |
Resolution | 0.01N.m |
Length | 260 mm |
Code | IST-WP12 | IST-WP20 |
Range | 2.4-12N.m | 4-20N.m |
Accuracy Clockwise | ±3% | ±3% |
Accuracy Counter-clockwise | ±4% | ±4% |
Resolution | 0.01 N.m | 0.01 N.m |
Square driver (L) | 1/4" | 1/4" |
Power supply | 1 xAAA batter | |
Length | 260 mm | 260 mm |
Weight | 430g | 430g |
Additional Information:
Approx. Rs 5,740 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Torque Range (Nm) | 5~25Nm |
Drive Size | 1/4 Inch |
Brand | INSIZE |
Warranty | 1 Year |
Model | INSIZE |
Item Weight (Kgs) | 590g |
Overall Length (mm) | 281MM |
Code | IST-1VVM25 | IST-1VVM100 | IST-1 VVM100A | IST-1WM200 | IST-1WM340 | IST-1VVM340A | IST-1WM550 | IST-1VVM750 |
Range (clockwise, unit: N.m) | 5 ~25 | 20 -100 | 20 -100 | 40 - 200 | 60 - 340 | 60 - 340 | 110-550 | 150-750 |
Accuracy | ±4% | ±4% | ±4% | ±4% | ±4% | ±4% | ±4% | ±4% |
Graduation | 0.1N.m | 0.5N.m | 0.5N.m | 0.5N.m | 1N.m | 1N.m | 2N. m | 2.5N.m |
Square driver (D) | 1/4" | 3/8" | 1/2" | 1/2" | 1/2" | 3/4" | 3/4" | 3/4" |
Dimension (LxWxH, unit: mm) | 323 x23x21 | 400x32x29 | 400 x32x32 | 517x40 x39 | 620 x40x37 | 620 x40x46 | 918 x60x55 | 1210x60x55 |
Weight | 760g | 988g | 998g | 1360g | 1730g | 1784g | 4528g | 5850g |
We provide NABL tracable calibration certificate. calibration charges will be extra.
Additional Information:
Approx. Rs 81,094 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Brand | Insize |
Code | IST-TT5 | IST-TT50 | IST-TT220 | IST-TT550 | IST-TT2200 |
Range | 0.5-5N.m | 5-50N.m | 22-220N.m | 55-550N.m | 220-2200N.m |
Accuracy | ±0.5% (clockwise and counter-clockwise) | ||||
Resolution | 0.001N.m | 0.01N.m | 0.1N.m | 0.1N.m | 1N.m |
Square socket (L) | 1/4" | 3/8" | 1/2" | 3/4" | 1" |
Power supply | Built-in rechargeable battery | ||||
Adaptor | no | 3/8" to 1/4" | 1/2" to 3/8" 3/8" to 1/4" | 3/4" to 1/2" 1/2" to 3/8" | 1" to 3/4" 3/4" to 1/2" |
Transducer dimension | 60x60x47 kg | 89x89x65 kg | 109x109x73 kg | 140x140x97 kg | 160x160x116 kg |
Weight | 0.7 kg | 1.1 kg | 1.4 kg | 2.8 kg | 4.7 kg |
Additional Information:
Approx. Rs 1.7 Lakh / PieceGet Latest Price
Product Details:Minimum Order Quantity | 1 Piece |
Brand | Insize |
Resolution 0.01N.m. Clamping range Ø19.5~190mm. Accuracy ±0.5% (of load capacity). Measuring mode: tracking, peak (max.), first peak, double peak, low and high limits with judgement. Output: wireless and USB. Measure the open and tighten torque of bottle cap. Units: N.m, N.cm, kgf.cm, lbf.in, lbf.ft. 1500 memories. Wireless connection to printer. Automatic power off. LCD display with backlight. Overload alarm. With calibration function.
Additional Information:
Approx. Rs 25,811 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Warranty | 1 Year |
Code | IST-SD50 | IST-SD200 | IST-SD400 |
Range | 10-50cN.m | 40-200cN.m | 80-400cN.m |
Accuracy Clockwise | ±3% | ±2.5% | ±2.5% |
Accuracy Counter-clockwise | ±4% | ±3.5% | ±3.5% |
Resolution | 0.1cN.m | 0.1cN.m | 0.1cN.m |
Size of shank (L) | 1/4" | 1/4" | 1/4" |
Power supply | 1 xAAA battery | ||
Length | 193 mm | 203 mm | 203 mm |
Weight | 190g | 200g | 200g |
Additional Information:
Approx. Rs 12,166 / UnitGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Unit |
Drive Size | 1/4 Inch |
Model | IST-DW3D5, IST-DW3D5 |
Weight | 0.48 KG |
Brand | Insize |
Overall Length | 254 mm |
Warranty | 1 Year |
Usage/Application | Workshop |
Metric Resolution | 0.02-50 |
Type | Torque Wrench |
We provide NABL tracable calibration certificate. calibration charges will be extra.
Additional Information:
Approx. Rs 72,525 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Torque Range (Nm) | 5 - 35 Nm |
Drive Size | 1/4 Inch |
Brand | Insize |
Warranty | 1 Year |
Model | IST-3W30A |
Item Weight (Kgs) | 0.760 |
Overall Length (mm) | 390 |
Accuracy: clockwise ±2%, counter-clockwise ±3%. Tolerance setting range -25% ~ +25% (target torque value). Resolution 0.01N.m. Square driver(L) 1/4". Wireless data transfer to computer. Unit: N.m, in.lb, ft.lb, kg.cm. Clockwise and counter-clockwise operation. Peak and track working mode. Can set tolerance with judgement in peak working mode. 9 target torque values can be set, with audible and visible alarm: green LED light on and buzzer sounds when torque value is 80% ~ 99.5% of target torque, both green and red LED light on and buzzer sounds when torque value is over 99.5% of target torque. Power off in 2 minutes automatically. Non-slip grip handle. With damp record. With overload record (once the torque reaches 110% of the maximum range). We provide NABL tracable calibration certificate. calibration charges will be extra. |
Additional Information:
Approx. Rs 35,595 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Torque Range (Nm) | 5 - 35 Nm |
Overall Length (mm) | 390 mm |
Brand | Insize |
Warranty | 1 Year |
Model | IST-1W30A |
Item Weight (Kgs) | 0.83 |
We provide NABL tracable calibration certificate. calibration charges will be extra.
Additional Information:
Approx. Rs 13,805 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Overall Length (mm) | 4~20 N.m |
Warranty | 1 Year |
Model | IST8WM20 |
Item Weight (Kgs) | 1372g |
Type | Torque Wrench |
Graduation | 0.1N.m. |
Arm Length L1 | 261mm |
We provide NABL tracable calibration certificate. calibration charges will be extra.
Additional Information:
Approx. Rs 1.44 Lakh / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Type | Torque testers |
Screen | Digital |
Model | IST-TT5, IST-TT50, IST-TT220, IST-TT550 |
material | MS, Aluminium |
Additional Information:
