Home » Our Products » Profile Projector


Profile Projector

Measure coordinate of point measure distance between two objects measure coordinate of line measure center coordinate, radius of circle with three points set origin of coordinate measure angle with four points or two lines coordinate transform set of coordinate.

Horizontal Profile Projector

REQUEST CALLBACK

Horizontal Profile Projector
Get Best Quote

Thanks for Contacting Us.

Approx. Rs 10.38 Lakh / PieceGet Latest Price

Product Brochure
Product Details:
Minimum Order Quantity1 Piece
ConditionNew
Load Capacity (Kilogram)50 Kg
Part View OrientationHorizontal
Screen (millimetre)400mm
Warranty (month)12
DesignHORIZONTAL

Edge detector not included. Lens: 5X (optional), 10X (standard), 20X (optional), 50X (optional), 100X (optional). Projector screen diameter Ø400mm. X-Z stage travel: range 250×150mm, resolution 0.5μm. Y (focus) travel range 100mm.

We provide NABL tracable calibration certificate. calibration charges will be extra.



Additional Information:

  • Item Code: ISP-W4025
  • Production Capacity: As per Clint requirement
  • Delivery Time: ex-stock
  • Packaging Details: As per Clint requirement
Yes! I am interested

Profile Projector

REQUEST CALLBACK

Profile Projector
Get Best Quote

Thanks for Contacting Us.

Approx. Rs 3.91 Lakh / PieceGet Latest Price

Product Brochure
Product Details:
Minimum Order Quantity1 Piece
ConditionNew
GradeAutomatic
Load Capacity (Kilogram)4 KG
Part View OrientationHorizontal
Range of Y coordinates150X50mm
Range of Z coordinates90mm
Screen (millimetre)300mm
Stage Effective Glass Size (millimetre)196x96mm
Warranty (month)12 months

Leverage on our vast industry experience, we are involved in offering a wide range of Insize Profile Projector. This profile projector is manufactured using best material & leading techniques in compliance with the set norms of industry. Offered profile projector projects a magnified profile image of an area or feature of a work piece onto a screen. Our profile projector is tested by our quality controllers to guarantee the flawlessness.

Features:

  • High Accuracy
  • Reliability
  • Unmatched quality

Other Details:


  • Lens
  • Rotary table (glass plate diameter 100 mm)
  • Overlay chart (protractor with 1° graduation, radius with 1 mm increment)
  • Holder with clamp
  • Swivel center support
  • V-block with clamp
  • 50 mm reading scale (check magnification accuracy)
  • 300 mm calibration scale (check magnification accuracy together
  • With 50mm reading scale or calibrate measuring accuracy)
  • Blue filter
  • Demo sample
  • Edge detector (for 10x lens only)
  • Printer


Additional Information:

  • Item Code: ISP-Z3015
  • Pay Mode Terms: T/T (Bank Transfer)
  • Port of Dispatch: Ahmedabad
  • Delivery Time: Ex stock
Yes! I am interested

Profile Projectors

REQUEST CALLBACK

Profile Projectors
Get Best Quote

Thanks for Contacting Us.

Approx. Rs 5.13 Lakh / PieceGet Latest Price

Product Brochure
Product Details:
Minimum Order Quantity1 Piece
ConditionNew
Focus Range (millimetre)90 mm
GradeSemi-Automatic
Load Capacity (Kilogram)135 kg
Part View OrientationHorizontal
Range of X coordinates150

Edge detector not included. Lens: 10X(included), 20X(optional), 50X(optional), 100X(optional). Projector screen diameter Ø300mm. X-Y stage travel: range 150×50mm, resolution 0.5μm. Z (focus) travel range 90mm.


Additional Information:

  • Item Code: ISP-A1000E
  • Pay Mode Terms: T/T (Bank Transfer)
  • Production Capacity: As per Clint requirement
  • Delivery Time: with in 15 Days
  • Packaging Details: As per Clint requirement
Yes! I am interested

Horizontal Profile Projector

REQUEST CALLBACK

Horizontal Profile Projector
Get Best Quote

Thanks for Contacting Us.

Approx. Rs 8.26 Lakh / PieceGet Latest Price

Product Brochure
Product Details:
Minimum Order Quantity1 Piece
ConditionNew

We are instrumental in offering and extensive range of Horizontal Profile Projector. Comes with Xenon lamp Light source for better contrast & life, this profile projector is manufactured at vendor’s end using best quality material and latest technology. The profile projector offered by us is provided in number of specifications as per the needs of customers. Our offered profile projector has hard chrome plated cross table with slots for clamping of accessories.

Features:

  • Compact size
  • Rugged construction
  • Easy to install

Other Details:


  • Lens
  • Overlay chart (protractor with 1° graduation, radius with 1 mm increment)
  • 50 mm reading scale (check magnification accuracy)
  • 300 mm calibration scale (check magnification accuracy together
  • With 50mm reading scale or calibrate measuring accuracy)
  • Demo sample
  • V-block with clamp
  • Rotary table
  • Vise
  • Edge detector (for 10X lens only)
  • Printer


Additional Information:

  • Item Code: ISP-W3020
  • Pay Mode Terms: T/T (Bank Transfer)
  • Port of Dispatch: Ahmedabad
  • Delivery Time: Ex stock
Yes! I am interested
